Details
- •Relays
- •Timer relay
- •1 KOM
- •ABB
Technical specifications
Height85.6mm
With plug-in socketNo
Remote operation possibleNo
Suitable as remote controlNo
Depth103.7mm
Suitable for front mountingNo
Function flashing, starting with pause, fixed timeNo
Clock function, starting with pause, variableNo
Function flashing, starting with pulse, fixed timeYes
Function floating contact on de-energizationYes
Time range0.05 - 1080000s
Function pulse shapingYes
Clock function, starting with pulse, variableNo
Function star-deltaYes
With semiconductor outputNo
Function floating contact on energizationYes
Rated control supply voltage Us at AC 60HZ24 - 240V
Function delay-on energizationYes
Function delay on de-energizationYes
Number of outputs, undelayed, change-over contact2
Number of outputs, undelayed, normally open contact0
Outputs, reversible delayed/undelayedNo
Number of outputs, undelayed, normally closed contact0
Pluggable on auxiliary contact blockNo
Number of outputs, delayed, normally open contact0
Rated control supply voltage Us at DC24 - 48V
Number of outputs, delayed, normally closed contact0
Type of electric connectionSpring clamp connection
Suitable for DIN rail (top hat rail) mountingYes
Type of excitationAnalogue with multi function
Number of outputs, delayed, change-over contact2
Width22.5mm
Nominal current4A
Rated control supply voltage Us at AC 50HZ24 - 240V
Voltage type for actuatingAC/DC
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SVR740020R3300 | CT-MVS.22P
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Relays
- Timer relay
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Height
85.6mm
With plug-in socket
Remote operation possible
Suitable as remote control
Depth
103.7mm
Suitable for front mounting
Function flashing, starting with pause, fixed time
Clock function, starting with pause, variable
Function flashing, starting with pulse, fixed time
Function floating contact on de-energization
Time range
0.05 .. 1080000s
Function pulse shaping
Clock function, starting with pulse, variable
Function star-delta
With semiconductor output
Function floating contact on energization
Rated control supply voltage Us at AC 60HZ
24 .. 240V
Function delay-on energization
Function delay on de-energization
Number of outputs, undelayed, change-over contact
2
Number of outputs, undelayed, normally open contact
0
Outputs, reversible delayed/undelayed
Number of outputs, undelayed, normally closed contact
0
Pluggable on auxiliary contact block
Number of outputs, delayed, normally open contact
0
Rated control supply voltage Us at DC
24 .. 48V
Number of outputs, delayed, normally closed contact
0
Type of electric connection
Spring clamp connection
Suitable for DIN rail (top hat rail) mounting
Type of excitation
Analogue with multi function
Number of outputs, delayed, change-over contact
2
Width
22.5mm
Nominal current
4A
Rated control supply voltage Us at AC 50HZ
24 .. 240V
Voltage type for actuating
AC/DC
