Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Release characteristicK
Rated impulse withstand voltage Uimp8kV
Rated voltage500V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V50kA
Number of poles (total)2
Number of protected poles2
Rated current20A
Rated insulation voltage Ui1000V
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V50kA
Voltage typeAC/DC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V50kA
Frequency50 - 60Hz
Suitable for flush-mounted installationNo
Concurrently switching neutral conductorNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V50kA
Pollution degree2
Width in number of modular spacings2
Over voltage category3
Current limiting class3
Built-in depth82.5mm
Additional equipment possibleYes
Ambient temperature during operating-25 - 60°C
Degree of protection (IP)IP20
Connectable conductor cross section solid-core0 - 50mm²
Connectable conductor cross section multi-wired0 - 70mm²
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CCS862001R1487 | S802S-UCK20
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Release characteristic
K
Rated impulse withstand voltage Uimp
8kV
Rated voltage
500V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
50kA
Number of poles (total)
2
Number of protected poles
2
Rated current
20A
Rated insulation voltage Ui
1000V
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
50kA
Voltage type
AC/DC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
50kA
Frequency
50 .. 60Hz
Suitable for flush-mounted installation
Concurrently switching neutral conductor
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
50kA
Pollution degree
2
Width in number of modular spacings
2
Over voltage category
3
Current limiting class
3
Built-in depth
82.5mm
Additional equipment possible
Ambient temperature during operating
-25 .. 60°C
Degree of protection (IP)
IP20
Connectable conductor cross section solid-core
0 .. 50mm²
Connectable conductor cross section multi-wired
0 .. 70mm²
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
