Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Pollution degree3
Rated voltage440V
Power loss12.8W
Degree of protection (IP)IP20
Number of protected poles2
Current limiting class3
Voltage typeAC
Rated insulation voltage Ui500V
Width in number of modular spacings2
Frequency50 - 60Hz
Release characteristicC
Over voltage category4
Built-in depth82.5mm
Rated current63A
Explosion-proofNo
Concurrently switching neutral conductorNo
Connectable conductor cross section multi-wired0 - 70mm²
Additional equipment possibleYes
Suitable for flush-mounted installationNo
Connectable conductor cross section solid-core0 - 50mm²
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V15kA
Ambient temperature during operating-25 - 60°C
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V25kA
Flush-mounted installationNo
Number of poles (total)2
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V25kA
Rated impulse withstand voltage Uimp8kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V15kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CCS882001R0634 | S802C-C63
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Pollution degree
3
Rated voltage
440V
Power loss
12.8W
Degree of protection (IP)
IP20
Number of protected poles
2
Current limiting class
3
Voltage type
AC
Rated insulation voltage Ui
500V
Width in number of modular spacings
2
Frequency
50 .. 60Hz
Release characteristic
C
Over voltage category
4
Built-in depth
82.5mm
Rated current
63A
Explosion-proof
Concurrently switching neutral conductor
Connectable conductor cross section multi-wired
0 .. 70mm²
Additional equipment possible
Suitable for flush-mounted installation
Connectable conductor cross section solid-core
0 .. 50mm²
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
15kA
Ambient temperature during operating
-25 .. 60°C
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
25kA
Flush-mounted installation
Number of poles (total)
2
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
25kA
Rated impulse withstand voltage Uimp
8kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
15kA
