Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Release characteristicB
Built-in depth82.5mm
Voltage typeAC/DC
Frequency50 - 60Hz
Rated current10A
Rated voltage400V
Current limiting class3
Over voltage category4
Degree of protection (IP)IP20
Connectable conductor cross section solid-core0 - 50mm²
Ambient temperature during operating-25 - 60°C
Width in number of modular spacings2
Pollution degree3
Rated insulation voltage Ui690V
Number of protected poles2
Concurrently switching neutral conductorNo
Suitable for flush-mounted installationNo
Connectable conductor cross section multi-wired0 - 70mm²
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V25kA
Rated impulse withstand voltage Uimp8kV
Number of poles (total)2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V25kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V36kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V36kA
Additional equipment possibleYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CCS892001R0105 | S802N-B10
