Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Built-in depth82.5mm
Voltage typeAC/DC
Rated current63A
Current limiting class3
Number of protected poles3
Rated voltage690V
Rated insulation voltage Ui690V
Concurrently switching neutral conductorNo
Release characteristicD
Pollution degree3
Ambient temperature during operating-25 - 60°C
Width in number of modular spacings3
Connectable conductor cross section multi-wired0 - 70mm²
Frequency50 - 60Hz
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V25kA
Degree of protection (IP)IP20
Suitable for flush-mounted installationNo
Over voltage category4
Connectable conductor cross section solid-core0 - 50mm²
Additional equipment possibleYes
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V25kA
Number of poles (total)3
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V36kA
Rated impulse withstand voltage Uimp8kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V36kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CCS893001R0631 | S803N-D63
