2CDS212001R0065 | SH202-B6
Code: 1548990
ManufacturerABB
Catalog number2CDS212001R0065
TypeSH202-B6
CategoryMiniature circuit breaker (MCB)
EAN code4016779631044
Details
- •MINIJATURNI PREKIDAC, 2P, 6A, B KRIVULJA, 6kA
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •Minimum order quantity: 1 pcs
- •ABB
Technical specifications
Built-in depth69mm
Frequency50 - 60Hz
Pollution degree2
Rated insulation voltage Ui440V
Over voltage category3
Current limiting class3
Explosion-proofNo
Degree of protection (IP)IP2X
Rated impulse withstand voltage Uimp4kV
Additional equipment possibleNo
Flush-mounted installationNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V6kA
Ambient temperature during operating-25 - 55°C
Suitable for flush-mounted installationNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V6kA
Concurrently switching neutral conductorNo
Power loss4W
Connectable conductor cross section multi-wired0 - 25mm²
Connectable conductor cross section solid-core0 - 25mm²
Number of protected poles2
Voltage typeAC
Rated voltage400V
Width in number of modular spacings2
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Rated current6A
Release characteristicB
Number of poles (total)2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
