2CDS253001R0105 | S203-B10
Code: 1549318
Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Release characteristicB
Number of poles (total)3
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Number of protected poles3
Current limiting class3
Rated impulse withstand voltage Uimp4kV
Pollution degree3
Width in number of modular spacings3
Connectable conductor cross section multi-wired0 - 25mm²
Suitable for flush-mounted installationNo
Ambient temperature during operating-25 - 55°C
Additional equipment possibleYes
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V20kA
Rated current10A
Over voltage category3
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
Built-in depth69mm
Rated insulation voltage Ui440V
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10kA
Frequency50 - 60Hz
Voltage typeAC
Rated voltage400V
Concurrently switching neutral conductorNo
Connectable conductor cross section solid-core0 - 35mm²
Degree of protection (IP)IP20
Explosion-proofNo
Flush-mounted installationNo
Power loss6.3W
From same serie
