Details

  • •Circuit breakers and fuses
  • •Miniature circuit breaker (MCB)
  • •1 KOM
  • •ABB

Technical specifications

Built-in depth69mm
Voltage typeAC
Frequency50 - 60Hz
Rated voltage400V
Over voltage category3
Suitable for flush-mounted installationNo
Rated insulation voltage Ui440V
Connectable conductor cross section solid-core0 - 35mm²
Concurrently switching neutral conductorNo
Pollution degree3
Degree of protection (IP)IP20
Current limiting class3
Additional equipment possibleYes
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V20kA
Connectable conductor cross section multi-wired0 - 25mm²
Ambient temperature during operating-25 - 55°C
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10kA
Width in number of modular spacings3
Number of protected poles3
Rated current16A
Release characteristicD
Number of poles (total)3
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
