Details

  • •Circuit breakers and fuses
  • •Miniature circuit breaker (MCB)
  • •1 KOM
  • •ABB

Technical specifications

Ambient temperature during operating-25 - 55°C
Flush-mounted installationNo
Voltage typeAC
Concurrently switching neutral conductorNo
Connectable conductor cross section solid-core0 - 35mm²
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Rated voltage400V
Pollution degree3
Additional equipment possibleYes
Frequency50 - 60Hz
Built-in depth69mm
Over voltage category3
Suitable for flush-mounted installationNo
Connectable conductor cross section multi-wired0 - 25mm²
Rated insulation voltage Ui440V
Current limiting class3
Power loss7.2W
Explosion-proofNo
Width in number of modular spacings3
Degree of protection (IP)IP20
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V20kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
Release characteristicZ
Number of poles (total)3
Rated current3A
Number of protected poles3
