2CDS274001R0254 | S204M-C25
Code: 1550198
ManufacturerABB
Catalog number2CDS274001R0254
TypeS204M-C25
CategoryMiniature circuit breaker (MCB)
EAN code4016779550772
Details
- •MINIJATURNI PREKIDAC, 4P, 25A, C KRIVULJA, 15kA
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •Minimum order quantity: 1 pcs
- •ABB
Technical specifications
Frequency50 - 60Hz
Current limiting class3
Built-in depth71mm
Pollution degree2
Rated insulation voltage Ui440V
Over voltage category3
Voltage typeAC/DC
Number of protected poles4
Degree of protection (IP)IP20
Connectable conductor cross section solid-core0 - 35mm²
Rated impulse withstand voltage Uimp4kV
Suitable for flush-mounted installationNo
Concurrently switching neutral conductorNo
Connectable conductor cross section multi-wired0 - 25mm²
Ambient temperature during operating-25 - 55°C
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V15kA
Rated voltage400V
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15kA
Width in number of modular spacings4
Additional equipment possibleYes
Rated current25A
Release characteristicC
Number of poles (total)4
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
