Details
- •NH-FUSE-DISCON. NH00 160A
- •Low-voltage control systems
- •Fuse switch disconnector
- •Minimum order quantity: 1 pcs
- •ABB
Technical specifications
Rated short-time withstand current lcw50kA
Rated operation power at AC-23, 400 V-kW
Version as emergency stop installationNo
Conditioned rated short-circuit current Iq50kA
Version as main switchYes
Version as safety switchNo
Cable entryOther
Type of control elementCover grip
Type of electrical connection of main circuitScrew connection
Degree of protection (IP), front sideIP30
Motor drive integratedNo
Suitable for front mountingYes
Suitable for floor mountingNo
Suitable for busbar mountingNo
Position control elementFront side
Motor drive optionalNo
Equipped with connectorsNo
With error protectionNo
Rated permanent current Iu160A
Number of poles3
Suitable for fusesNH00
Max. rated operation voltage Ue AC400V
