Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Release characteristicC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V4.5kA
Rated current16A
Over voltage category3
Concurrently switching neutral conductorYes
Current limiting class3
Width in number of modular spacings2
Frequency0 - 60Hz
Pollution degree2
Suitable for flush-mounted installationNo
Additional equipment possibleYes
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V4.5kA
Connectable conductor cross section multi-wired0 - 10mm²
Rated insulation voltage Ui500V
Number of protected poles1
Voltage typeAC/DC
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V4.5kA
Degree of protection (IP)IP20
Rated voltage230V
Built-in depth76mm
Number of poles (total)2
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V6kA
Ambient temperature during operating-25 - 55°C
Connectable conductor cross section solid-core0 - 16mm²
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CSS245101R0164 | SN201 L C16
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Release characteristic
C
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
4.5kA
Rated current
16A
Over voltage category
3
Concurrently switching neutral conductor
Current limiting class
3
Width in number of modular spacings
2
Frequency
0 .. 60Hz
Pollution degree
2
Suitable for flush-mounted installation
Additional equipment possible
Rated impulse withstand voltage Uimp
4kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
4.5kA
Connectable conductor cross section multi-wired
0 .. 10mm²
Rated insulation voltage Ui
500V
Number of protected poles
1
Voltage type
AC/DC
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
4.5kA
Degree of protection (IP)
IP20
Rated voltage
230V
Built-in depth
76mm
Number of poles (total)
2
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
6kA
Ambient temperature during operating
-25 .. 55°C
Connectable conductor cross section solid-core
0 .. 16mm²
