Details

  • •Circuit breakers and fuses
  • •Miniature circuit breaker (MCB)
  • •1 KOM
  • •ABB

Technical specifications

Over voltage category3
Voltage typeAC/DC
Frequency0 - 50Hz
Pollution degree2
Current limiting class3
Rated insulation voltage Ui500V
Built-in depth76mm
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Connectable conductor cross section multi-wired0 - 10mm²
Ambient temperature during operating-25 - 55°C
Connectable conductor cross section solid-core0 - 16mm²
Degree of protection (IP)IP20
Additional equipment possibleYes
Suitable for flush-mounted installationNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10kA
Rated impulse withstand voltage Uimp4kV
Number of protected poles1
Rated voltage230V
Width in number of modular spacings1
Concurrently switching neutral conductorYes
Rated current6A
Release characteristicC
Number of poles (total)2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
