Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •SOCOMEC
Technical specifications
Rated permanent current Iu160A
Conditioned rated short-circuit current Iq50kA
Number of poles3
Rated operating voltage400 - 690V
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Degree of protection (IP), front sideIP20
Motor drive integratedNo
Type of electrical connection of main circuitScrew connection
Number of auxiliary contacts as change-over contact0
Version as main switchYes
Version as emergency stop installationYes
Suitable for front mounting 4-holeYes
InterlockableYes
Suitable for floor mountingYes
Rated operation power at AC-23, 400 V160kW
Colour control elementOther
Number of switches1
Version as safety switchYes
Rated short-time withstand current lcw7kA
Type of control elementOther
Suitable for front mounting centreNo
Version as maintenance-/service switchYes
Suitable for intermediate mountingYes
Max. rated operation voltage Ue AC800V
Switching power at 400 V75kW
Suitable for distribution board installationYes
Voltage release optionalNo
Motor drive optionalNo
Device constructionBuilt-in device fixed built-in technique
Rated permanent current at AC-21, 400 V160A
Rated permanent current at AC-23, 400 V160A
Version as reversing switchNo
