Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •1 KOM
- •EATON
Technical specifications
Width160mm
Number of normally open contacts as main contact3
Rated operation power at AC-3, 400 V200kW
Depth216mm
Height209mm
Modular versionNo
Number of normally closed contacts as main contact0
Operating voltage at AC 60 Hz110 - 250V
Voltage type for actuatingAC/DC
Rated operation current Ie at AC-3, 400 V400A
Number of auxiliary contacts as normally closed contact2
Rated operation current Ie at AC-1, 400 V612A
Rated control supply voltage Us at DC110 - 250V
Type of electrical connection of main circuitRail connection
Rated control supply voltage Us at AC 50HZ110 - 250V
Operating voltage at AC 50 Hz110 - 250V
Number of auxiliary contacts as normally open contact2
Rated control supply voltage Us at AC 60HZ110 - 250V
Rated operation current Ie at AC-4, 400 V296A
Rated operation power NEMA223kW
Rated operation power at AC-4, 400 V160kW
