Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •2 KOM
- •EATON
Technical specifications
Voltage protection level1.4kV
Mounting methodOn basic element
Max. continuous voltage AC280V
Construction size1 modular spacing
Number of conductors (without earthing)0
With remote signalling contactNo
Category type 2Yes
Nominal voltage DC0V
Voltage protection level N-PE0kV
Max. conductor cross section solid (solid, stranded)25mm²
Voltage protection level L-N0kV
Integrated backup fuseNo
Signalling at the deviceOptic
Max. continuous voltage DC0V
Max. conductor cross section flexible (fine-strand)0mm²
Max. PV-voltage0V
System configuration DCNo
System configuration ITNo
System configuration TNYes
System configuration TN-SNo
System configuration TTNo
System configuration TN-CNo
Max. overcurrent protection device, parallel connection (fuse)0A
System configuration TN-C-SNo
Max. discharge surge current (8/20)40kA
Max. overcurrent protection device, series connection (fuse)125A
Short-circuit breaking capacity (Isccr)0kA
Integrated short-circuit protection selective to fuse gG0A
Integrated short-circuit protectionNo
System configuration otherYes
Leakage-current freeNo
Nominal discharge surge current (8/20)20kA
Nominal voltage AC280V
Degree of protection (IP)IP20
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SPCT2-280
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Earthing, lightning and surge protection
- Surge protection device for power supply systems
- 2 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Voltage protection level
1.4kV
Mounting method
On basic element
Max. continuous voltage AC
280V
Construction size
1 modular spacing
Number of conductors (without earthing)
0
With remote signalling contact
Category type 2
Nominal voltage DC
0V
Voltage protection level N-PE
0kV
Max. conductor cross section solid (solid, stranded)
25mm²
Voltage protection level L-N
0kV
Integrated backup fuse
Signalling at the device
Optic
Max. continuous voltage DC
0V
Max. conductor cross section flexible (fine-strand)
0mm²
Max. PV-voltage
0V
System configuration DC
System configuration IT
System configuration TN
System configuration TN-S
System configuration TT
System configuration TN-C
Max. overcurrent protection device, parallel connection (fuse)
0A
System configuration TN-C-S
Max. discharge surge current (8/20)
40kA
Max. overcurrent protection device, series connection (fuse)
125A
Short-circuit breaking capacity (Isccr)
0kA
Integrated short-circuit protection selective to fuse gG
0A
Integrated short-circuit protection
System configuration other
Leakage-current free
Nominal discharge surge current (8/20)
20kA
Nominal voltage AC
280V
Degree of protection (IP)
IP20
