Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •EATON
Technical specifications
Number of conductors (without earthing)2
Mounting methodDIN rail (top hat rail) 35 mm
Max. continuous voltage AC335V
With remote signalling contactNo
Voltage protection level1.6kV
Construction size2 modular spacing
Nominal voltage DC0V
Voltage protection level N-PE0kV
Category type 2Yes
Voltage protection level L-N0kV
Integrated backup fuseNo
System configuration ITNo
Signalling at the deviceOptic
Max. PV-voltage0V
System configuration TTNo
Max. conductor cross section flexible (fine-strand)35mm²
Max. continuous voltage DC0V
System configuration TNYes
Max. conductor cross section solid (solid, stranded)25mm²
System configuration TN-CNo
System configuration DCNo
System configuration TN-SYes
Integrated short-circuit protectionNo
Max. overcurrent protection device, series connection (fuse)125A
Integrated short-circuit protection selective to fuse gG0A
Max. overcurrent protection device, parallel connection (fuse)0A
Short-circuit breaking capacity (Isccr)0kA
Max. discharge surge current (8/20)40kA
System configuration TN-C-SNo
System configuration otherYes
Leakage-current freeNo
Nominal discharge surge current (8/20)20kA
Nominal voltage AC335V
Degree of protection (IP)IP20
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SPCT2-335/2
