Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •EATON
Technical specifications
Max. continuous voltage AC335V
Number of conductors (without earthing)3
Voltage protection level1.6kV
Mounting methodDIN rail (top hat rail) 35 mm
With remote signalling contactNo
Construction size3 modular spacing
Signalling at the deviceOptic
Voltage protection level L-N0kV
Degree of protection (IP)IP20
Max. PV-voltage0V
Nominal voltage AC335V
Nominal voltage DC0V
Voltage protection level N-PE0kV
Max. continuous voltage DC0V
Category type 2Yes
Nominal discharge surge current (8/20)20kA
Integrated backup fuseNo
Max. conductor cross section solid (solid, stranded)25mm²
Max. conductor cross section flexible (fine-strand)35mm²
System configuration DCNo
System configuration ITNo
Max. overcurrent protection device, series connection (fuse)125A
System configuration TNYes
System configuration TN-SYes
Max. discharge surge current (8/20)40kA
Leakage-current freeNo
Integrated short-circuit protection selective to fuse gG0A
Short-circuit breaking capacity (Isccr)0kA
Integrated short-circuit protectionNo
System configuration otherYes
Max. overcurrent protection device, parallel connection (fuse)0A
System configuration TN-CYes
System configuration TTNo
System configuration TN-C-SNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SPCT2-335/3
