Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •EATON
Technical specifications
Number of conductors (without earthing)4
Mounting methodDIN rail (top hat rail) 35 mm
Voltage protection level1.8kV
With remote signalling contactNo
Construction size4 modular spacing
Voltage protection level N-PE0kV
Max. continuous voltage AC385V
Nominal voltage DC0V
Max. PV-voltage0V
Degree of protection (IP)IP20
Voltage protection level L-N0kV
Signalling at the deviceOptic
Max. conductor cross section solid (solid, stranded)25mm²
Category type 2Yes
System configuration ITNo
System configuration TNYes
System configuration TN-CNo
Nominal voltage AC385V
Max. conductor cross section flexible (fine-strand)35mm²
Max. continuous voltage DC0V
System configuration DCNo
Nominal discharge surge current (8/20)20kA
Integrated backup fuseNo
System configuration TN-C-SYes
Max. overcurrent protection device, parallel connection (fuse)0A
System configuration TN-SYes
Short-circuit breaking capacity (Isccr)0kA
System configuration TTNo
System configuration otherYes
Max. discharge surge current (8/20)40kA
Leakage-current freeNo
Integrated short-circuit protectionNo
Max. overcurrent protection device, series connection (fuse)125A
Integrated short-circuit protection selective to fuse gG0A
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SPCT2-385/4
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Earthing, lightning and surge protection
- Surge protection device for power supply systems
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Number of conductors (without earthing)
4
Mounting method
DIN rail (top hat rail) 35 mm
Voltage protection level
1.8kV
With remote signalling contact
Construction size
4 modular spacing
Voltage protection level N-PE
0kV
Max. continuous voltage AC
385V
Nominal voltage DC
0V
Max. PV-voltage
0V
Degree of protection (IP)
IP20
Voltage protection level L-N
0kV
Signalling at the device
Optic
Max. conductor cross section solid (solid, stranded)
25mm²
Category type 2
System configuration IT
System configuration TN
System configuration TN-C
Nominal voltage AC
385V
Max. conductor cross section flexible (fine-strand)
35mm²
Max. continuous voltage DC
0V
System configuration DC
Nominal discharge surge current (8/20)
20kA
Integrated backup fuse
System configuration TN-C-S
Max. overcurrent protection device, parallel connection (fuse)
0A
System configuration TN-S
Short-circuit breaking capacity (Isccr)
0kA
System configuration TT
System configuration other
Max. discharge surge current (8/20)
40kA
Leakage-current free
Integrated short-circuit protection
Max. overcurrent protection device, series connection (fuse)
125A
Integrated short-circuit protection selective to fuse gG
0A
