Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •EATON
Technical specifications
Max. continuous voltage AC460V
Nominal voltage AC460V
Nominal voltage DC0V
Mounting methodOn basic element
Construction size1 modular spacing
With remote signalling contactNo
Category type 2Yes
Voltage protection level2.2kV
Degree of protection (IP)IP20
Max. PV-voltage0V
Number of conductors (without earthing)0
Voltage protection level L-N0kV
Nominal discharge surge current (8/20)20kA
Signalling at the deviceOptic
Max. continuous voltage DC0V
Integrated backup fuseNo
Voltage protection level N-PE0kV
Max. conductor cross section solid (solid, stranded)0mm²
System configuration DCNo
System configuration TN-SNo
System configuration ITNo
Max. conductor cross section flexible (fine-strand)0mm²
System configuration TNYes
System configuration TTNo
System configuration TN-CNo
System configuration TN-C-SNo
Short-circuit breaking capacity (Isccr)0kA
Max. discharge surge current (8/20)40kA
Max. overcurrent protection device, series connection (fuse)125A
Max. overcurrent protection device, parallel connection (fuse)0A
System configuration otherYes
Leakage-current freeNo
Integrated short-circuit protection selective to fuse gG0A
Integrated short-circuit protectionNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SPCT2-460
