SPCT2-460/4
Code: 1579703
Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •EATON
Technical specifications
System configuration TNYes
System configuration ITYes
System configuration TN-C-SYes
System configuration TN-CNo
System configuration TN-SYes
System configuration TTNo
Max. discharge surge current (8/20)40kA
Number of conductors (without earthing)4
Nominal discharge surge current (8/20)20kA
System configuration otherYes
Nominal voltage DC0V
Max. continuous voltage AC460V
System configuration DCNo
Nominal voltage AC460V
Voltage protection level2.2kV
Max. overcurrent protection device, parallel connection (fuse)0A
Max. continuous voltage DC0V
Max. PV-voltage0V
Voltage protection level N-PE0kV
Short-circuit breaking capacity (Isccr)0kA
Voltage protection level L-N0kV
Max. overcurrent protection device, series connection (fuse)125A
Integrated short-circuit protection selective to fuse gG0A
Leakage-current freeNo
Integrated backup fuseNo
Integrated short-circuit protectionNo
Mounting methodDIN rail (top hat rail) 35 mm
Max. conductor cross section solid (solid, stranded)25mm²
Degree of protection (IP)IP20
Category type 2Yes
Construction size4 modular spacing
With remote signalling contactNo
Signalling at the deviceOptic
Max. conductor cross section flexible (fine-strand)35mm²
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SPCT2-460/4
Details
- Earthing, lightning and surge protection
- Surge protection device for power supply systems
- 1 KOM
- EATON
DetailsTechnical specificationsFrom same serie
Technical specifications
System configuration TN
System configuration IT
System configuration TN-C-S
System configuration TN-C
System configuration TN-S
System configuration TT
Max. discharge surge current (8/20)
40kA
Number of conductors (without earthing)
4
Nominal discharge surge current (8/20)
20kA
System configuration other
Nominal voltage DC
0V
Max. continuous voltage AC
460V
System configuration DC
Nominal voltage AC
460V
Voltage protection level
2.2kV
Max. overcurrent protection device, parallel connection (fuse)
0A
Max. continuous voltage DC
0V
Max. PV-voltage
0V
Voltage protection level N-PE
0kV
Short-circuit breaking capacity (Isccr)
0kA
Voltage protection level L-N
0kV
Max. overcurrent protection device, series connection (fuse)
125A
Integrated short-circuit protection selective to fuse gG
0A
Leakage-current free
Integrated backup fuse
Integrated short-circuit protection
Mounting method
DIN rail (top hat rail) 35 mm
Max. conductor cross section solid (solid, stranded)
25mm²
Degree of protection (IP)
IP20
Category type 2
Construction size
4 modular spacing
With remote signalling contact
Signalling at the device
Optic
Max. conductor cross section flexible (fine-strand)
35mm²
From same serie
