Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •EATON
Technical specifications
With remote signalling contactNo
Construction size2 modular spacing
Number of conductors (without earthing)1
Voltage protection level2.2kV
Mounting methodDIN rail (top hat rail) 35 mm
Max. continuous voltage AC460V
Nominal voltage DC0V
System configuration TN-C-SNo
System configuration otherYes
System configuration TNYes
System configuration TTYes
Max. conductor cross section solid (solid, stranded)25mm²
Max. conductor cross section flexible (fine-strand)35mm²
Signalling at the deviceOptic
System configuration ITYes
Degree of protection (IP)IP20
System configuration TN-CNo
Voltage protection level N-PE0kV
Category type 2Yes
Integrated backup fuseNo
Nominal voltage AC460V
System configuration TN-SYes
Max. discharge surge current (8/20)40kA
System configuration DCNo
Nominal discharge surge current (8/20)20kA
Max. continuous voltage DC0V
Voltage protection level L-N0kV
Max. PV-voltage0V
Max. overcurrent protection device, series connection (fuse)125A
Short-circuit breaking capacity (Isccr)0kA
Max. overcurrent protection device, parallel connection (fuse)0A
Leakage-current freeNo
Integrated short-circuit protectionNo
Integrated short-circuit protection selective to fuse gG0A
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SPCT2-460-1+NPE
