Details
- •Devices for distribution board-/surface mounting
- •Digital time switch for distribution board
- •1 KOM
- •EATON
Technical specifications
Width17.5mm
Astro programNo
Radio-controlledNo
Quartz controlledYes
Depth65.5mm
60 min programYes
Number of contacts1
Cycle programNo
Annual programNo
GPS (global positioning system)No
Height90mm
Mains synchronousNo
Random programNo
Number of memory locations84
Impulse programNo
Width in number of modular spacings1
24 h programYes
Contact typeChange-over contact (NO/NC)
Switching preselectionYes
Automatic switching summer-/winter timeYes
Suitable for manual operationYes
Output signalOther
Holiday programYes
Frequency supply voltage50 - 60Hz
Potential free switch contactYes
Shortest switching time channel 11min
External programmingYes
Hour meterYes
Text guidance in displayYes
With memory cardNo
Shortest switching time channel 20min
Max. switching power LED600W
Autonomy in years10
Radio-controlled (DCF77)No
External pushbutton inputNo
Accuracy per day1s
Autonomy in hours0
Weekly programYes
Mounting methodDIN rail
Number of channels1
Voltage type of supply voltageAC
Supply voltage230 - 240V
Nominal switching current at 250 V AC16A
Degree of protection (IP)IP20
