Details
- •Sensors
- •Inductive proximity switch
- •1 KOM
- •EATON
Technical specifications
Voltage typeDC
CascadableNo
Suitable for safety functionsNo
Type of interface for safety communicationNone
Number of protected contact energized outputs0
Switching frequency100Hz
Number of semiconductor outputs with signalling function0
Switching distance8mm
Rated control supply voltage Us at DC15 - 30V
Explosion safety category for gasNone
Rated control supply voltage Us at AC 50HZ0 - 0V
Number of contact energized outputs with signalling function0
Number of protected semiconductor outputs0
Type of switching outputOther
Mechanical mounting condition for sensorNot flat
Explosion safety category for dustNone
Type of switch functionOther
Category according to EN 954-1B
Rated control supply voltage Us at AC 60HZ0 - 0V
Construction type housingCylinder, screw-thread
Max. output current at protected output20mA
Supply voltage15 - 30V
Coating housingOther
Material housingMetal
Type of electric connectionCable
With monitoring function downstream switching devicesNo
Type of actuationMetallic Target
Width sensor0mm
Compression-resistantNo
Performance level according to EN ISO 13849-1None
SIL according to IEC 61508None
Height of sensor0mm
Length of sensor62.4mm
Diameter sensor12mm
Type of interfaceNone
