Details
- •Sensors
- •Inductive proximity switch
- •1 KOM
- •EATON
Technical specifications
Coating housingOther
Switching frequency100Hz
Suitable for safety functionsNo
CascadableNo
Material housingMetal
Voltage typeDC
Number of semiconductor outputs with signalling function0
Number of protected contact energized outputs0
Number of protected semiconductor outputs0
Type of interface for safety communicationNone
Switching distance8mm
Type of switching outputOther
Type of electric connectionOther
Number of contact energized outputs with signalling function0
Type of switch functionOther
Rated control supply voltage Us at AC 50HZ0 - 0V
Explosion safety category for dustNone
Construction type housingCylinder, screw-thread
Rated control supply voltage Us at AC 60HZ0 - 0V
Rated control supply voltage Us at DC15 - 30V
Explosion safety category for gasNone
Supply voltage15 - 30V
Max. output current at protected output20mA
Mechanical mounting condition for sensorNot flat
With monitoring function downstream switching devicesNo
Compression-resistantNo
Type of actuationMetallic Target
Type of interfaceNone
Diameter sensor12mm
Height of sensor0mm
Width sensor0mm
Length of sensor77.5mm
Degree of protection (NEMA)4X, 6, 13
SIL according to IEC 61508None
Performance level according to EN ISO 13849-1None
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
E59-A12C108D01-CV
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- Inductive proximity switch
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Coating housing
Other
Switching frequency
100Hz
Suitable for safety functions
Cascadable
Material housing
Metal
Voltage type
DC
Number of semiconductor outputs with signalling function
0
Number of protected contact energized outputs
0
Number of protected semiconductor outputs
0
Type of interface for safety communication
None
Switching distance
8mm
Type of switching output
Other
Type of electric connection
Other
Number of contact energized outputs with signalling function
0
Type of switch function
Other
Rated control supply voltage Us at AC 50HZ
0 .. 0V
Explosion safety category for dust
None
Construction type housing
Cylinder, screw-thread
Rated control supply voltage Us at AC 60HZ
0 .. 0V
Rated control supply voltage Us at DC
15 .. 30V
Explosion safety category for gas
None
Supply voltage
15 .. 30V
Max. output current at protected output
20mA
Mechanical mounting condition for sensor
Not flat
With monitoring function downstream switching devices
Compression-resistant
Type of actuation
Metallic Target
Type of interface
None
Diameter sensor
12mm
Height of sensor
0mm
Width sensor
0mm
Length of sensor
77.5mm
Degree of protection (NEMA)
4X, 6, 13
SIL according to IEC 61508
None
Performance level according to EN ISO 13849-1
None
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
