Details
- •Sensors
- •Inductive proximity switch
- •1 KOM
- •EATON
Technical specifications
Switching distance12mm
Number of semiconductor outputs with signalling function0
Voltage typeDC
Number of protected semiconductor outputs0
Material housingMetal
Suitable for safety functionsNo
Number of contact energized outputs with signalling function0
Rated control supply voltage Us at AC 50HZ0 - 0V
Coating housingOther
Switching frequency140Hz
CascadableNo
Type of switch functionOther
Type of electric connectionCable
Type of switching outputOther
Number of protected contact energized outputs0
Type of interface for safety communicationNone
Rated control supply voltage Us at AC 60HZ0 - 0V
Explosion safety category for dustNone
Max. output current at protected output20mA
Rated control supply voltage Us at DC15 - 30V
Construction type housingCylinder, screw-thread
Mechanical mounting condition for sensorConcise
Explosion safety category for gasNone
With monitoring function downstream switching devicesNo
Supply voltage15 - 30V
Diameter sensor30mm
Width sensor0mm
Type of actuationMetallic Target
Compression-resistantNo
Type of interfaceNone
Category according to EN 954-1B
Height of sensor0mm
Performance level according to EN ISO 13849-1None
Length of sensor69.6mm
SIL according to IEC 61508None
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
E59-A30A112C02-CV
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- Inductive proximity switch
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Switching distance
12mm
Number of semiconductor outputs with signalling function
0
Voltage type
DC
Number of protected semiconductor outputs
0
Material housing
Metal
Suitable for safety functions
Number of contact energized outputs with signalling function
0
Rated control supply voltage Us at AC 50HZ
0 .. 0V
Coating housing
Other
Switching frequency
140Hz
Cascadable
Type of switch function
Other
Type of electric connection
Cable
Type of switching output
Other
Number of protected contact energized outputs
0
Type of interface for safety communication
None
Rated control supply voltage Us at AC 60HZ
0 .. 0V
Explosion safety category for dust
None
Max. output current at protected output
20mA
Rated control supply voltage Us at DC
15 .. 30V
Construction type housing
Cylinder, screw-thread
Mechanical mounting condition for sensor
Concise
Explosion safety category for gas
None
With monitoring function downstream switching devices
Supply voltage
15 .. 30V
Diameter sensor
30mm
Width sensor
0mm
Type of actuation
Metallic Target
Compression-resistant
Type of interface
None
Category according to EN 954-1
B
Height of sensor
0mm
Performance level according to EN ISO 13849-1
None
Length of sensor
69.6mm
SIL according to IEC 61508
None
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
