Details
- •Sensors
- •Inductive proximity switch
- •1 KOM
- •EATON
Technical specifications
Switching frequency140Hz
Material housingMetal
Voltage typeDC
CascadableNo
Coating housingOther
Suitable for safety functionsNo
Number of protected semiconductor outputs0
Switching distance12mm
Number of contact energized outputs with signalling function0
Number of protected contact energized outputs0
Number of semiconductor outputs with signalling function0
Type of interface for safety communicationNone
Rated control supply voltage Us at AC 60HZ0 - 0V
Explosion safety category for dustNone
Type of electric connectionOther
Type of switching outputOther
Type of switch functionOther
Rated control supply voltage Us at AC 50HZ0 - 0V
Rated control supply voltage Us at DC15 - 30V
Explosion safety category for gasNone
With monitoring function downstream switching devicesNo
Supply voltage15 - 30V
Max. output current at protected output20mA
Construction type housingCylinder, screw-thread
Mechanical mounting condition for sensorConcise
Category according to EN 954-1B
Type of actuationMetallic Target
Type of interfaceNone
Width sensor0mm
Diameter sensor30mm
Compression-resistantNo
Height of sensor0mm
Performance level according to EN ISO 13849-1None
SIL according to IEC 61508None
Length of sensor74.1mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
E59-A30A112D01-C1
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- Inductive proximity switch
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Switching frequency
140Hz
Material housing
Metal
Voltage type
DC
Cascadable
Coating housing
Other
Suitable for safety functions
Number of protected semiconductor outputs
0
Switching distance
12mm
Number of contact energized outputs with signalling function
0
Number of protected contact energized outputs
0
Number of semiconductor outputs with signalling function
0
Type of interface for safety communication
None
Rated control supply voltage Us at AC 60HZ
0 .. 0V
Explosion safety category for dust
None
Type of electric connection
Other
Type of switching output
Other
Type of switch function
Other
Rated control supply voltage Us at AC 50HZ
0 .. 0V
Rated control supply voltage Us at DC
15 .. 30V
Explosion safety category for gas
None
With monitoring function downstream switching devices
Supply voltage
15 .. 30V
Max. output current at protected output
20mA
Construction type housing
Cylinder, screw-thread
Mechanical mounting condition for sensor
Concise
Category according to EN 954-1
B
Type of actuation
Metallic Target
Type of interface
None
Width sensor
0mm
Diameter sensor
30mm
Compression-resistant
Height of sensor
0mm
Performance level according to EN ISO 13849-1
None
SIL according to IEC 61508
None
Length of sensor
74.1mm
