Details
- •Sensors
- •Reflection light barrier
- •1 KOM
- •EATON
Technical specifications
Voltage typeDC
Max. output current100mA
Material housingPlastic
With time functionNo
Switching frequency500Hz
Number of semiconductor outputs with signalling function1
Suitable for safety functionsNo
Ambient temperature25 - 55°C
Number of contact energized outputs with signalling function0
Type of switching outputNPN
Type of electric connectionConnector M8
Number of protected semiconductor outputs0
Number of protected contact energized outputs0
Rated control supply voltage Us at DC10 - 30V
Type of switch functionOther
Setting procedureOther
Type of lightPolarity free red light
Explosion safety category for dustNone
Laser protection classNone
Rated control supply voltage Us at AC 60HZ0 - 0V
Construction type housingCuboid
Rated control supply voltage Us at AC 50HZ0 - 0V
Switching voltage of OSSD at state "high"30V
Transmission range of the safety field0m
Max. output current at protected output0mA
Min. reflector distance0mm
With restart blockageNo
Response time1ms
With monitoring function downstream switching devicesNo
Explosion safety category for gasNone
Light dot0mm²
Wavelength of the sensor660nm
Pre failure noticeNo
Material of optical surfacePlastic
Analogue output 0 V ... 10 VNo
Analogue output 0 mA ... 20 mANo
Analogue output 4 mA ... 20 mANo
Degree of protection (IP)IP66
With communication interface RS-485No
With communication interface SSDNo
With communication interface RS-232No
With communication interface DeviceNetNo
With communication interface AS-InterfaceNo
With communication interface EthernetNo
With communication interface CANOpenNo
With communication interface RS-422No
Diameter sensor0mm
With communication interface SSINo
Height of sensor32mm
Width sensor12mm
With communication interface analogueNo
With communication interface INTERBUSNo
With communication interface PROFIBUSNo
Length of sensor20mm
Analogue output -10 V ... +10 VNo
Max. switching distance800mm
Rated switching distance800mm
Degree of protection (NEMA)Other
Sensing modeLight-/dark switching
With other analogue outputNo
With reflectorNo
