Details
- •Relays
- •Residual current monitoring relay
- •1 KOM
- •ABB
Technical specifications
Width48mm
FunctionFor mixed system
Type of electric connectionScrew connection
Error registration possibleNo
With detachable clampsNo
Height48mm
Rated control supply voltage Us at AC 50HZ110 - 230V
Depth92mm
Rated frequency50 - 60Hz
Rated control supply voltage Us at AC 60HZ110 - 230V
Indication of difference currentYes
Rated voltage110 - 230V
Response value amperage 130 - 30mA
Voltage type for actuatingAC/DC
Number of contacts as change-over contact2
Number of contacts as normally closed contact-
Response value amperage 230000 - 30000mA
Number of contacts as normally open contact-
Rated control supply voltage Us at DC110 - 230V
Min. adjustable delay-on energization time0s
Max. permitted delay-on energization time5s
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CSG252211R1202 | ELR48P
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Relays
- Residual current monitoring relay
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Width
48mm
Function
For mixed system
Type of electric connection
Screw connection
Error registration possible
With detachable clamps
Height
48mm
Rated control supply voltage Us at AC 50HZ
110 .. 230V
Depth
92mm
Rated frequency
50 .. 60Hz
Rated control supply voltage Us at AC 60HZ
110 .. 230V
Indication of difference current
Rated voltage
110 .. 230V
Response value amperage 1
30 .. 30mA
Voltage type for actuating
AC/DC
Number of contacts as change-over contact
2
Number of contacts as normally closed contact
-
Response value amperage 2
30000 .. 30000mA
Number of contacts as normally open contact
-
Rated control supply voltage Us at DC
110 .. 230V
Min. adjustable delay-on energization time
0s
Max. permitted delay-on energization time
5s
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
