Details
- •Low-voltage control systems
- •Switch disconnector (AC)
- •1 KOM
- •ABB
Technical specifications
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Rated operating voltage750 - 750V
Conditioned rated short-circuit current Iq-kA
Number of auxiliary contacts as change-over contact0
Number of switches1
Motor drive integratedNo
Version as emergency stop installationNo
Version as main switchYes
Type of control elementTurn button
Rated short-time withstand current lcw-kA
Rated operation power at AC-23, 400 V11kW
Voltage release optionalNo
Colour control elementBlack
Suitable for front mounting centreNo
Suitable for distribution board installationNo
Suitable for floor mountingNo
Motor drive optionalNo
Suitable for intermediate mountingNo
Suitable for front mounting 4-holeYes
Rated permanent current at AC-23, 400 V23A
Version as reversing switchNo
Rated permanent current at AC-21, 400 V40A
Switching power at 400 V11kW
Version as safety switchYes
Degree of protection (IP), front sideIP65
Version as maintenance-/service switchYes
Device constructionComplete device in housing
Colour housingGrey
InterlockableYes
Material housingPlastic
Rated permanent current Iu40A
Number of poles4
Max. rated operation voltage Ue AC750V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022562R3800 | OTL32B4M
