Details
- •Low-voltage control systems
- •Switch disconnector (AC)
- •1 KOM
- •ABB
Technical specifications
Version as main switchYes
Type of control elementTurn button
Number of auxiliary contacts as normally open contact1
Version as emergency stop installationNo
Number of auxiliary contacts as normally closed contact0
Height200mm
Width150mm
Depth100mm
Number of auxiliary contacts as change-over contact0
Conditioned rated short-circuit current Iq-kA
Rated operation power at AC-3, 400 V-kW
Number of switches1
Motor drive integratedNo
Width in number of modular spacings-
Rated operating voltage750 - 750V
Rated permanent current at AC-23, 400 V16A
Suitable for intermediate mountingNo
With pre-assembled cablingNo
Rated short-time withstand current lcw-kA
Rated permanent current at AC-21, 400 V32A
Version as maintenance-/service switchYes
Voltage release optionalNo
Suitable for distribution board installationNo
Suitable for floor mountingNo
Motor drive optionalNo
Rated operation power at AC-23, 400 V7.5kW
Switching power at 400 V7.5kW
Version as reversing switchNo
Suitable for front mounting centreNo
Suitable for front mounting 4-holeYes
Version as safety switchYes
Device constructionComplete device in housing
Colour housingGrey
InterlockableYes
Degree of protection (IP), front sideIP65
Colour control elementRed
Material housingPlastic
Rated permanent current Iu16A
Number of poles3
Max. rated operation voltage Ue AC750V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022575R1630 | OTL16A3B
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage control systems
- Switch disconnector (AC)
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Version as main switch
Type of control element
Turn button
Number of auxiliary contacts as normally open contact
1
Version as emergency stop installation
Number of auxiliary contacts as normally closed contact
0
Height
200mm
Width
150mm
Depth
100mm
Number of auxiliary contacts as change-over contact
0
Conditioned rated short-circuit current Iq
-kA
Rated operation power at AC-3, 400 V
-kW
Number of switches
1
Motor drive integrated
Width in number of modular spacings
-
Rated operating voltage
750 .. 750V
Rated permanent current at AC-23, 400 V
16A
Suitable for intermediate mounting
With pre-assembled cabling
Rated short-time withstand current lcw
-kA
Rated permanent current at AC-21, 400 V
32A
Version as maintenance-/service switch
Voltage release optional
Suitable for distribution board installation
Suitable for floor mounting
Motor drive optional
Rated operation power at AC-23, 400 V
7.5kW
Switching power at 400 V
7.5kW
Version as reversing switch
Suitable for front mounting centre
Suitable for front mounting 4-hole
Version as safety switch
Device construction
Complete device in housing
Colour housing
Grey
Interlockable
Degree of protection (IP), front side
IP65
Colour control element
Red
Material housing
Plastic
Rated permanent current Iu
16A
Number of poles
3
Max. rated operation voltage Ue AC
750V
