Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Conditioned rated short-circuit current Iq80kA
Cable entryOther
Suitable for fusesNH0
Rated permanent current Iu200A
Motor drive integratedNo
Number of poles3
Version as safety switchYes
Version as emergency stop installationNo
Type of electrical connection of main circuitBolt connection
Version as main switchYes
Type of control elementShort thumb-grip
Suitable for floor mountingNo
Suitable for busbar mountingYes
Rated short-time withstand current lcw8kA
Rated operation power at AC-23, 400 V200kW
Suitable for front mountingNo
Max. rated operation voltage Ue AC1000V
Motor drive optionalNo
Equipped with connectorsYes
Position control elementLeft
With error protectionNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022871R0720 | OS200DS03
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Conditioned rated short-circuit current Iq
80kA
Cable entry
Other
Suitable for fuses
NH0
Rated permanent current Iu
200A
Motor drive integrated
Number of poles
3
Version as safety switch
Version as emergency stop installation
Type of electrical connection of main circuit
Bolt connection
Version as main switch
Type of control element
Short thumb-grip
Suitable for floor mounting
Suitable for busbar mounting
Rated short-time withstand current lcw
8kA
Rated operation power at AC-23, 400 V
200kW
Suitable for front mounting
Max. rated operation voltage Ue AC
1000V
Motor drive optional
Equipped with connectors
Position control element
Left
With error protection
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
