Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Cable entryOther
Rated permanent current Iu200A
Number of poles4
Type of electrical connection of main circuitBolt connection
Version as safety switchYes
Suitable for floor mountingNo
Type of control elementShort thumb-grip
Motor drive integratedNo
Version as emergency stop installationNo
Conditioned rated short-circuit current Iq80kA
Max. rated operation voltage Ue AC1000V
Rated short-time withstand current lcw8kA
Rated operation power at AC-23, 400 V200kW
Suitable for fusesNH0
Version as main switchYes
With error protectionNo
Suitable for busbar mountingYes
Motor drive optionalNo
Suitable for front mountingNo
Equipped with connectorsYes
Position control elementLeft
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022871R0990 | OS200DS04F
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Cable entry
Other
Rated permanent current Iu
200A
Number of poles
4
Type of electrical connection of main circuit
Bolt connection
Version as safety switch
Suitable for floor mounting
Type of control element
Short thumb-grip
Motor drive integrated
Version as emergency stop installation
Conditioned rated short-circuit current Iq
80kA
Max. rated operation voltage Ue AC
1000V
Rated short-time withstand current lcw
8kA
Rated operation power at AC-23, 400 V
200kW
Suitable for fuses
NH0
Version as main switch
With error protection
Suitable for busbar mounting
Motor drive optional
Suitable for front mounting
Equipped with connectors
Position control element
Left
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
