Details
- •Low-voltage control systems
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Motor drive integratedNo
Version as emergency stop installationNo
Type of electrical connection of main circuitBolt connection
Type of control elementShort thumb-grip
Conditioned rated short-circuit current Iq80kA
Suitable for front mountingNo
Rated operation power at AC-23, 400 V132kW
Equipped with connectorsYes
Version as safety switchYes
Rated short-time withstand current lcw5kA
Suitable for floor mountingNo
Version as main switchYes
Suitable for busbar mountingYes
With error protectionNo
Motor drive optionalNo
Number of poles3
Rated permanent current Iu160A
Cable entryTop/bottom
Max. rated operation voltage Ue AC690V
Position control elementFront side
Suitable for fusesNH000, NH00
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA114221R1001 | OS160GD03
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage control systems
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specificationsFrom same serie
Technical specifications
Motor drive integrated
Version as emergency stop installation
Type of electrical connection of main circuit
Bolt connection
Type of control element
Short thumb-grip
Conditioned rated short-circuit current Iq
80kA
Suitable for front mounting
Rated operation power at AC-23, 400 V
132kW
Equipped with connectors
Version as safety switch
Rated short-time withstand current lcw
5kA
Suitable for floor mounting
Version as main switch
Suitable for busbar mounting
With error protection
Motor drive optional
Number of poles
3
Rated permanent current Iu
160A
Cable entry
Top/bottom
Max. rated operation voltage Ue AC
690V
Position control element
Front side
Suitable for fuses
NH000, NH00
From same serie
