Details
- •Low-voltage control systems
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Cable entryOther
Version as main switchYes
Type of control elementLong turning handle
Suitable for floor mountingNo
Rated operation power at AC-23, 400 V55kW
Suitable for busbar mountingYes
Suitable for front mountingNo
Version as emergency stop installationNo
Rated short-time withstand current lcw2.5kA
With error protectionNo
Type of electrical connection of main circuitScrew connection
Motor drive integratedNo
Conditioned rated short-circuit current Iq80kA
Version as safety switchYes
Position control elementFront side
Motor drive optionalNo
Equipped with connectorsYes
Rated permanent current Iu63A
Number of poles3
Suitable for fusesOther
Max. rated operation voltage Ue AC1000V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA115449R1001 | OS60GJ12P
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage control systems
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Cable entry
Other
Version as main switch
Type of control element
Long turning handle
Suitable for floor mounting
Rated operation power at AC-23, 400 V
55kW
Suitable for busbar mounting
Suitable for front mounting
Version as emergency stop installation
Rated short-time withstand current lcw
2.5kA
With error protection
Type of electrical connection of main circuit
Screw connection
Motor drive integrated
Conditioned rated short-circuit current Iq
80kA
Version as safety switch
Position control element
Front side
Motor drive optional
Equipped with connectors
Rated permanent current Iu
63A
Number of poles
3
Suitable for fuses
Other
Max. rated operation voltage Ue AC
1000V
