Details
- •Low-voltage control systems
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Conditioned rated short-circuit current Iq80kA
Motor drive integratedNo
Suitable for fusesOther
Cable entryOther
Rated operation power at AC-23, 400 V55kW
Suitable for front mountingNo
Type of control elementLong turning handle
Rated short-time withstand current lcw2.5kA
Suitable for busbar mountingYes
Version as safety switchYes
Suitable for floor mountingNo
Type of electrical connection of main circuitScrew connection
Version as main switchYes
Version as emergency stop installationNo
Equipped with connectorsYes
With error protectionNo
Max. rated operation voltage Ue AC1000V
Motor drive optionalNo
Rated permanent current Iu63A
Position control elementFront side
Number of poles4
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA115469R1001 | OS60GJ22FP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage control systems
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Conditioned rated short-circuit current Iq
80kA
Motor drive integrated
Suitable for fuses
Other
Cable entry
Other
Rated operation power at AC-23, 400 V
55kW
Suitable for front mounting
Type of control element
Long turning handle
Rated short-time withstand current lcw
2.5kA
Suitable for busbar mounting
Version as safety switch
Suitable for floor mounting
Type of electrical connection of main circuit
Screw connection
Version as main switch
Version as emergency stop installation
Equipped with connectors
With error protection
Max. rated operation voltage Ue AC
1000V
Motor drive optional
Rated permanent current Iu
63A
Position control element
Front side
Number of poles
4
