Details
- •Low-voltage control systems
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Cable entryOther
Motor drive integratedNo
Type of electrical connection of main circuitScrew connection
Conditioned rated short-circuit current Iq80kA
Version as emergency stop installationNo
Type of control elementLong turning handle
Rated short-time withstand current lcw2.5kA
Suitable for busbar mountingYes
Version as safety switchYes
Suitable for floor mountingNo
Version as main switchYes
Rated operation power at AC-23, 400 V37kW
Suitable for front mountingNo
Motor drive optionalNo
With error protectionNo
Equipped with connectorsYes
Number of poles4
Suitable for fuses14x51 mm
Rated permanent current Iu50A
Position control elementFront side
Max. rated operation voltage Ue AC690V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA115498R1001 | OS50GF04FP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage control systems
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Cable entry
Other
Motor drive integrated
Type of electrical connection of main circuit
Screw connection
Conditioned rated short-circuit current Iq
80kA
Version as emergency stop installation
Type of control element
Long turning handle
Rated short-time withstand current lcw
2.5kA
Suitable for busbar mounting
Version as safety switch
Suitable for floor mounting
Version as main switch
Rated operation power at AC-23, 400 V
37kW
Suitable for front mounting
Motor drive optional
With error protection
Equipped with connectors
Number of poles
4
Suitable for fuses
14x51 mm
Rated permanent current Iu
50A
Position control element
Front side
Max. rated operation voltage Ue AC
690V
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
