Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Cable entryOther
Suitable for fusesOther
Motor drive integratedNo
Number of poles4
Rated permanent current Iu160A
Conditioned rated short-circuit current Iq80kA
Rated operation power at AC-23, 400 V132kW
Version as safety switchYes
Suitable for busbar mountingYes
Version as main switchYes
Type of electrical connection of main circuitBolt connection
Suitable for front mountingNo
Type of control elementShort thumb-grip
Suitable for floor mountingNo
Rated short-time withstand current lcw5kA
Max. rated operation voltage Ue AC1000V
With error protectionNo
Position control elementFront side
Equipped with connectorsYes
Motor drive optionalNo
Version as emergency stop installationNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA115668R1001 | OS100GJ22F
