Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Conditioned rated short-circuit current Iq80kA
Rated permanent current Iu125A
Type of electrical connection of main circuitBolt connection
Number of poles3
Version as emergency stop installationNo
Version as main switchYes
Type of control elementShort thumb-grip
Version as safety switchYes
Motor drive integratedNo
Cable entryOther
Suitable for fusesNH000, NH00
Rated operation power at AC-23, 400 V110kW
Rated short-time withstand current lcw5kA
Suitable for floor mountingNo
Suitable for busbar mountingYes
Max. rated operation voltage Ue AC1000V
Position control elementFront side
Motor drive optionalNo
Suitable for front mountingNo
With error protectionNo
Equipped with connectorsYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA121679R1001 | OS125GD21
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Conditioned rated short-circuit current Iq
80kA
Rated permanent current Iu
125A
Type of electrical connection of main circuit
Bolt connection
Number of poles
3
Version as emergency stop installation
Version as main switch
Type of control element
Short thumb-grip
Version as safety switch
Motor drive integrated
Cable entry
Other
Suitable for fuses
NH000, NH00
Rated operation power at AC-23, 400 V
110kW
Rated short-time withstand current lcw
5kA
Suitable for floor mounting
Suitable for busbar mounting
Max. rated operation voltage Ue AC
1000V
Position control element
Front side
Motor drive optional
Suitable for front mounting
With error protection
Equipped with connectors
