Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally open contact0
Number of poles3
Rated permanent current Iu2000A
Number of auxiliary contacts as normally closed contact0
Type of control elementPush button
Motor drive optionalYes
Motor drive integratedNo
Overload release current setting800.0 - 2000A
Position of connection for main current circuitBack side
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz66kA
Degree of protection (IP)IP30
With switched-off indicatorYes
With integrated under voltage releaseNo
Adjustment range undelayed short-circuit release3000.0 - 30000A
Number of auxiliary contacts as change-over contact4
Adjustment range short-term delayed short-circuit release1200.0 - 20000A
Rated voltage690 - 690V
Suitable for DIN rail (top hat rail) mountingNo
Device constructionBuilt-in device fixed built-in technique
Integrated earth fault protectionNo
Type of electrical connection of main circuitBolt connection
Complete device with protection unitYes
DIN rail (top hat rail) mounting optionalNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA071035R1 | E2.2N 2000 EKIP TOUCH LSI 3P FHR
