2CDS272061R0024 | S202M-C2UC
Code: 1617716
Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V15kA
Rated current2A
Rated impulse withstand voltage Uimp4kV
Number of poles (total)2
Rated voltage400V
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15kA
Frequency50 - 60Hz
Release characteristicC
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
Number of protected poles2
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Current limiting class3
Concurrently switching neutral conductorNo
Rated insulation voltage Ui440V
Suitable for flush-mounted installationNo
Voltage typeAC/DC
Width in number of modular spacings2
Additional equipment possibleYes
Connectable conductor cross section solid-core0 - 35mm²
Pollution degree2
Connectable conductor cross section multi-wired0 - 25mm²
Degree of protection (IP)IP20
Built-in depth69mm
Ambient temperature during operating-25 - 55°C
Over voltage category3
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CDS272061R0024 | S202M-C2UC
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
15kA
Rated current
2A
Rated impulse withstand voltage Uimp
4kV
Number of poles (total)
2
Rated voltage
400V
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
15kA
Frequency
50 .. 60Hz
Release characteristic
C
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10kA
Number of protected poles
2
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10kA
Current limiting class
3
Concurrently switching neutral conductor
Rated insulation voltage Ui
440V
Suitable for flush-mounted installation
Voltage type
AC/DC
Width in number of modular spacings
2
Additional equipment possible
Connectable conductor cross section solid-core
0 .. 35mm²
Pollution degree
2
Connectable conductor cross section multi-wired
0 .. 25mm²
Degree of protection (IP)
IP20
Built-in depth
69mm
Ambient temperature during operating
-25 .. 55°C
Over voltage category
3
