Details
- •Energy distribution systems
- •Electricity meter
- •1 KOM
- •ABB
Technical specifications
Mounting methodDRA (DIN-rail adapter)
Suitable forPurchase/supply
Type of indicationDigital
Accuracy classB
CalibratedYes
Pulse rate1 - 999999Imp/kWh (kvarh)
Tariff typeMulti-tariff
Pole typeSingle phase
Degree of protection (IP)IP20
Type of interfaceModbus
ModelDirect measurement
Number of positions total (counter)6
Energy typeEffective power and blind power
ApprovalMeasuring Instruments Directive
EEC40 signatureNo
Measurement type load profileNo
Pulse typeS0
Escapement mechanismYes
Pulse outputElectrical
Type of meterElectronic
Tariff controlExternal
With lock codeNo
Degree of protection (NEMA)Other
Nominal voltage (Un) N-L220 - 240V
Nominal current (In)65A
Nominal voltage (Un) L-L220 - 240V
Frequency50 - 60Hz
Max. current (Imax)65A
Width in number of modular spacings2
