Technical specifications
Number of auxiliary contacts as normally open contact3
Rated operation power at AC-3, 400 V-kW
Rated permanent current Iu400A
Number of auxiliary contacts as normally closed contact0
Conditioned rated short-circuit current Iq50kA
Rated operating voltage400 - 690V
Number of poles4
Degree of protection (IP), front sideIP20
Number of auxiliary contacts as change-over contact0
Version as emergency stop installationNo
Type of electrical connection of main circuitBolt connection
Number of switches2
Suitable for intermediate mountingYes
Suitable for distribution board installationYes
Version as main switchNo
Version as maintenance-/service switchNo
Suitable for front mounting centreNo
Type of control elementLong turning handle
Rated short-time withstand current lcw8kA
Rated operation power at AC-23, 400 V-kW
Voltage release optionalNo
Suitable for front mounting 4-holeYes
Version as safety switchNo
Device constructionBuilt-in device fixed built-in technique
Rated permanent current at AC-21, 400 V400A
InterlockableYes
Suitable for floor mountingYes
Version as reversing switchYes
Motor drive optionalNo
Max. rated operation voltage Ue AC1000V
Colour control elementBlack
Switching power at 400 V-kW
Motor drive integratedYes
Rated permanent current at AC-23, 400 V400A
