Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •ABB
Technical specifications
Rated operation power at AC-3, 400 V-kW
Suitable for floor mountingNo
Suitable for intermediate mountingNo
Conditioned rated short-circuit current Iq-kA
Number of switches-
Number of auxiliary contacts as change-over contact0
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Version as maintenance-/service switchYes
Version as safety switchNo
Version as main switchYes
Rated operating voltage1000 - 1000V
Rated permanent current at AC-21, 400 V200A
Rated short-time withstand current lcw8kA
Max. rated operation voltage Ue AC1000V
Version as emergency stop installationNo
Rated operation power at AC-23, 400 V110kW
Switching power at 400 V110kW
Number of poles3
Voltage release optionalNo
Motor drive integratedNo
Colour control elementBlack
Rated permanent current Iu200A
Version as reversing switchNo
Suitable for distribution board installationYes
Type of electrical connection of main circuitBolt connection
Suitable for front mounting 4-holeNo
Degree of protection (IP), front sideOther
Degree of protection (NEMA)1
Motor drive optionalNo
Device constructionBuilt-in device fixed built-in technique
Rated permanent current at AC-23, 400 V250A
Suitable for front mounting centreNo
Type of control elementLong turning handle
InterlockableYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022709R9920 | OT200U03P
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Rated operation power at AC-3, 400 V
-kW
Suitable for floor mounting
Suitable for intermediate mounting
Conditioned rated short-circuit current Iq
-kA
Number of switches
-
Number of auxiliary contacts as change-over contact
0
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Version as maintenance-/service switch
Version as safety switch
Version as main switch
Rated operating voltage
1000 .. 1000V
Rated permanent current at AC-21, 400 V
200A
Rated short-time withstand current lcw
8kA
Max. rated operation voltage Ue AC
1000V
Version as emergency stop installation
Rated operation power at AC-23, 400 V
110kW
Switching power at 400 V
110kW
Number of poles
3
Voltage release optional
Motor drive integrated
Colour control element
Black
Rated permanent current Iu
200A
Version as reversing switch
Suitable for distribution board installation
Type of electrical connection of main circuit
Bolt connection
Suitable for front mounting 4-hole
Degree of protection (IP), front side
Other
Degree of protection (NEMA)
1
Motor drive optional
Device construction
Built-in device fixed built-in technique
Rated permanent current at AC-23, 400 V
250A
Suitable for front mounting centre
Type of control element
Long turning handle
Interlockable
