Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •ABB
Technical specifications
With remote signalling contactNo
Construction size1 modular spacing
Number of conductors (without earthing)1
Voltage protection level1kV
Nominal discharge surge current (8/20)5kA
Max. continuous voltage AC320V
Mounting methodDIN rail (top hat rail) 35 mm
Signalling at the deviceOptic
Max. continuous voltage DC-V
Voltage protection level L-N1.1kV
Nominal voltage DC-V
Nominal voltage AC277V
Category type 2Yes
Max. PV-voltage-V
Integrated backup fuseYes
System configuration TN-CYes
System configuration TNYes
Voltage protection level N-PE1.2kV
Max. conductor cross section solid (solid, stranded)25mm²
System configuration ITNo
Degree of protection (IP)IP20
System configuration DCNo
Max. conductor cross section flexible (fine-strand)16mm²
System configuration TN-C-SYes
System configuration otherYes
Max. discharge surge current (8/20)15kA
System configuration TTYes
Integrated short-circuit protectionNo
Short-circuit breaking capacity (Isccr)100kA
Max. overcurrent protection device, series connection (fuse)100A
Max. overcurrent protection device, parallel connection (fuse)-A
System configuration TN-SYes
Integrated short-circuit protection selective to fuse gG-A
Leakage-current freeNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CTB802341R0400 | OVRT215-320PU
