FAZT-C16/3
Code: 1635907
ManufacturerEaton
Catalog number240895
TypeFAZT-C16/3
CategoryMiniature circuit breaker (MCB)
EAN code4015082408954
Details
- •Circuit breaker, C char, 3-pole, Icu=25kA (IE
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Current limiting class3
Width in number of modular spacings3
Built-in depth70.5mm
Rated insulation voltage Ui440V
Voltage typeAC
Pollution degree2
Explosion-proofNo
Frequency50 - 60Hz
Power loss6.9W
Over voltage category3
Degree of protection (IP)IP20
Connectable conductor cross section multi-wired1 - 25mm²
Concurrently switching neutral conductorNo
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V15kA
Connectable conductor cross section solid-core1 - 25mm²
Ambient temperature during operating-25 - 75°C
Additional equipment possibleYes
Flush-mounted installationNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V25kA
Rated impulse withstand voltage Uimp4kV
Number of protected poles3
Rated voltage400V
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V25kA
Rated current16A
Release characteristicC
Number of poles (total)3
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V15kA
