Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Voltage typeAC
Built-in depth70mm
Rated voltage240V
Rated current13A
Release characteristicB
Leakage current typeA
Current limiting class3
Rated insulation voltage Ui250V
Rated fault current0.1A
Surge current capacity3kA
Over voltage category3
Width in number of modular spacings2
Pollution degree2
Connectable conductor cross section solid-core1 - 25mm²
Degree of protection (IP)IP20
Suitable for flush-mounted installationNo
Concurrently switching neutral conductorYes
Rated impulse withstand voltage Uimp4kV
Anti-nuisance tripping versionYes
Rated short-circuit breaking capacity according to IEC 60947-20kA
Rated short-circuit breaking capacity Icn according to EN 61009-110kA
Connectable conductor cross section multi-wired1 - 25mm²
Rated short-circuit breaking capacity according to EN 6100910kA
Disconnection characteristicShort-time delayed
Number of poles (total)2
Number of protected poles1
Frequency50 Hz
Ambient temperature during operating-25 - 40°C
With interlocking deviceNo
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBdM-B13/1N/01-G/A
