Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Rated insulation voltage Ui500V
Built-in depth75.5mm
Over voltage category3
Release characteristicB
Surge current capacity0.25kA
Current limiting class3
Degree of protection (IP)IP20
Pollution degree2
Voltage typeAC
Leakage current typeA
Rated current10A
Frequency50 Hz
Rated fault current0.03A
Width in number of modular spacings2
Rated short-circuit breaking capacity according to IEC 60947-20kA
Concurrently switching neutral conductorYes
Connectable conductor cross section solid-core1 - 25mm²
Number of protected poles1
Rated voltage240V
Flush-mounted installationNo
With interlocking deviceNo
Disconnection characteristicUndelayed
Number of poles (total)2
Rated short-circuit breaking capacity according to EN 610096kA
Connectable conductor cross section multi-wired1 - 25mm²
Rated short-circuit breaking capacity Icn according to EN 61009-16kA
Anti-nuisance tripping versionNo
Ambient temperature during operating-25 - 40°C
Rated impulse withstand voltage Uimp4kV
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBm6-B10/1N/003-A
