Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Leakage current typeAC
Voltage typeAC
Built-in depth75.5mm
Rated current10A
Rated voltage240V
Release characteristicB
Rated fault current0.03A
Rated insulation voltage Ui500V
Ambient temperature during operating-25 - 40°C
Connectable conductor cross section solid-core1 - 25mm²
Over voltage category3
Width in number of modular spacings2
Concurrently switching neutral conductorNo
Degree of protection (IP)IP20
Frequency50 Hz
Number of protected poles2
Connectable conductor cross section multi-wired1 - 25mm²
Current limiting class3
With interlocking deviceNo
Surge current capacity0.25kA
Rated short-circuit breaking capacity according to IEC 60947-20kA
Pollution degree2
Rated impulse withstand voltage Uimp4kV
Anti-nuisance tripping versionNo
Rated short-circuit breaking capacity according to EN 610096kA
Disconnection characteristicUndelayed
Rated short-circuit breaking capacity Icn according to EN 61009-16kA
Number of poles (total)2
Flush-mounted installationNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBm6-B10/2/003
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Earth leakage circuit breaker
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Leakage current type
AC
Voltage type
AC
Built-in depth
75.5mm
Rated current
10A
Rated voltage
240V
Release characteristic
B
Rated fault current
0.03A
Rated insulation voltage Ui
500V
Ambient temperature during operating
-25 .. 40°C
Connectable conductor cross section solid-core
1 .. 25mm²
Over voltage category
3
Width in number of modular spacings
2
Concurrently switching neutral conductor
Degree of protection (IP)
IP20
Frequency
50 Hz
Number of protected poles
2
Connectable conductor cross section multi-wired
1 .. 25mm²
Current limiting class
3
With interlocking device
Surge current capacity
0.25kA
Rated short-circuit breaking capacity according to IEC 60947-2
0kA
Pollution degree
2
Rated impulse withstand voltage Uimp
4kV
Anti-nuisance tripping version
Rated short-circuit breaking capacity according to EN 61009
6kA
Disconnection characteristic
Undelayed
Rated short-circuit breaking capacity Icn according to EN 61009-1
6kA
Number of poles (total)
2
Flush-mounted installation
