Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Surge current capacity0.25kA
Built-in depth75.5mm
Rated insulation voltage Ui500V
Concurrently switching neutral conductorNo
Rated fault current0.3A
Frequency50 Hz
Rated current10A
Pollution degree2
Release characteristicB
Suitable for flush-mounted installationNo
Over voltage category3
Width in number of modular spacings2
Rated voltage240V
Number of protected poles2
Current limiting class3
Voltage typeAC
Degree of protection (IP)IP20
Leakage current typeA
Rated short-circuit breaking capacity according to IEC 60947-20kA
Connectable conductor cross section solid-core1 - 25mm²
Connectable conductor cross section multi-wired1 - 25mm²
Anti-nuisance tripping versionNo
Ambient temperature during operating-25 - 40°C
Number of poles (total)2
Rated short-circuit breaking capacity according to EN 610096kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icn according to EN 61009-16kA
With interlocking deviceNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBm6-B10/2/03-A
